SPP-XF65 Self Priming Pumps
  • Description

    Our SPP-XF65 Self Priming Pumps with industry-leading efficiency, runs several percentage points higher than other manufacturers. Features patented Cycloseal® backplate and uniquely designed volute for best performance, with a 8” suction and 8” discharge.

    Enquire Now
Specifications
Min Flow 290 gpm 66.7 m3/h
Max Flow 2880 gpm 662.4 m3/h
Discharge Size 8” 200 mm
Suction Size 8” 200 mm
Solids Handling 3” 7.6 mm
Max Speed 1800 rpm 1800 rpm
Bep Head 146’ 44.5 m
Bep Flow 2260 gpm 513.3 m3/h
Advantages
  • Heavy-duty bearings with separate oil reserve
  • Back-pull out design for ease of maintenance
  • Self-cleaning adjustable wear plate
  • Patented Cornell Cycloseal® sealing system
  • Easily-replaceable suction check valve
  • Shimless impellers
  • Ductile iron construction
XF65-SERIES PUMPS:
  • The XF65 series is our standard self-primers are a premium efficiency wet prime pump, that after the initial filling, will re-prime in operation.
  • XF65 series, in 2” to 10”, are designed to work as a drop-in replacement for other Self Priming Pumps.
  • Our pumps feature a number of advantages over other self-primers though, including Cycloseal®, heavy-duty ductile iron castings, oversized steel shafts, double-lip seals for bearing protection, and efficiencies up to 8% higher than competitors.
XH65-SERIES PUMPS:
  • The XH65 Series design takes high-head Self Priming Pumps to the next level; hitting heads 20% higher than our competition.
  • The XH65 design runs at a slower RPM, while providing larger shafts and bearings to support the high head hydraulics.
  • The result is a pump that outperforms the competition in both durability and performance.
  • XH65 does not require a booster pump to hit heads of up to 253′ with up to 2,000 GPM.
XL65-SERIES PUMPS:

  • The XL65 self-priming pump is a premium efficiency wet prime pump developed to meet unique market needs.

  • While the XL65 has all of the great features you get from our XL65 and XL65 Series pumps, such as Cycloseal®, heavy-duty ductile iron       castings, oversized steel shafts, double-lip seals for bearing protection, it is also uniquely designed to run at 1800 RPM.

  • The higher speed capacity allows the pump to be used on engines applications without the need for speed reducing gear boxes.

  • Its performance exceeds the competition while providing the flexibility of both frame and SAE mount options.
