The Mission MAGNUM I has been engineered for the toughest jobs in drilling, production, well-servicing, and industrial applications.
The revolutionary design of the MAGNUM I provides supreme-duty performance in all types of fluid pumping operations. Although it offers greater capacity and higher heads, the MAGNUM I remains the competitive pump of choice for aggressive applications.
The MAGNUM I is more powerful, more durable, and easier to maintain than any conventional pump in use today.

The Magnum has an open impeller design that contains wide-tipped vanes and a more tangential circumference of the suction allowing the pump to create a smoother flow pattern when handling abrasive fluids. The Magnum is available in Magnachrome, hard iron, stainless steel, and aluminum bronze fluid ends. The pumps can be unitized with electric motors, diesel engines, and hydraulic motors (horizontal, vertical, or close-coupled configuration).
Typical Applications

• Barite, ferric oxide, and mineral oil
• Base drilling muds
• Glass fibers
• Sugar processing
• Ash or coal conveyers
• Cement
• Mine de-watering
• Lime slurries
• Kaolin clay
• Crystalline forms

According to the different working conditions, Mission centrifugal pumps can be used as Frac discharge pump, Frac suction pump, Oil drilling centrifugal pump, electric centrifugal transfer pump, Skid mounted mixing pump, Transfer pump, Trash pump, Grinding pump, Circulating mud pump, Centrifugal sludge pump, Drilling fluid centrifugal pump, Horizontal directional drilling pump, Denver pump, Filling pump, Feeding pump, etc

Design Features

• Versatile stuffing box
• One piece casing
• Casing gasket receded for protection
• Back vanes reduce collection of solids at stuffing box
• Long-life, no-adjustment mechanical seal available for near zero leakage
• Replaceable shaft sleeve
• Lip seals for maximum bearing protection (Labyrinth seals optional)
• Duplex angular contact bearings
• Thicker, stronger concentric casings
• Full pipe diameter entrance for minimum turbulence and maximum efficiency
• Single row roller bearings for increased bearing life
• Easy accessible front access drain
• Reduced high bearing loads

The post Mission Magnum I Pump 8x6x14 and Centrifugal Mud Pump appeared first on AVAengineering.

Design Characteristics

The AVA Engineering  Slurry Pump range is a cost-effective solution for medium-duty slurry applications, and the design allows for easy maintenance

Slurry Pump Features

Bearing assembly:
• Short overhang on shaft design – assists with shaft deflection as well as vibration
• Dimensional interchangeability to suit heavy-duty bearing assemblies

Liners:
• Ease of maintenance design allows interchangeability with High-Chrome, Elastomer, Rubber, Polyurethane, Ceramic and various other material options

Casing:
• Solid casing design
• Ease of rotation and maintenance on casing with improved clamp design

Impeller:
• Various impeller designs to suit any application
• Impeller adjustment via bearing assembly
• Expulsion vanes on impeller shroud, minimises

Stuffng box
• Various materials to suit any application

Sealing options:
• Stuffng box (full flow, low flow and ultra flow)
• Expeller seal,
• mechanical seal

The post 1.5/1B-AHR slurry pump headed to Germany appeared first on AVAengineering.

The pump body materials of centrifugal pumps are commonly cast iron, stainless steel, cast steel, bronze, composite materials, carbon structural steel, alloy steel and non-metallic materials. These factors should be considered when selecting materials: a strength; b corrosion resistance; ε resistance Abrasive weard casting and machining performance; ε welding repair performance; f cost. Now we come to the specific introduction.

One, cast iron

For most liquid transportation applications, gray cast iron is a better material for pump housing. For single-stage pumps, gray cast iron is usually strong enough to resist the pressure generated. In the medium pressure and temperature range, ductile iron is widely used. In applications where gray cast iron and ductile iron cannot achieve sufficient corrosion resistance, corrosion-resistant high nickel cast iron is often used as the pump body material. In recent years, a new type of corrosion-resistant nickel cast iron material (named D2W) with good welding performance has been developed, which contains a small amount of niobium to improve its welding performance. Typical austenitic cast iron contains 15920% nickel and is widely used in salt water.

Gray cast iron is the most commonly used cast iron, and the national standard code is HT. Generally, the pump body, impeller pump cover, suspension, etc. of clean water centrifugal pumps are made of this material, and three grades are usually used: HT150, HT200, HT250. HT150 is mostly used for non-main parts such as base and backing plate, pump body, pump Covers, suspensions, etc. mostly use HT200, while impellers, spigots, bushings, etc. mostly use HT250. The representation of gray iron varies from country to country. For example, the code name of Japan is FC, the code name of Germany is GG, and the United States is Cass4.

Nodular cast iron is a kind of cast iron with better comprehensive performance, and the national standard code is QT. Because its mechanical properties are close to steel, and its casting and processing properties are better than steel, it is usually used as a substitute for cast steel. The most commonly used grades are: QT450-10, QT500-7, QT600-3. Due to the limitations of casting and other reasons, the impeller of the current water pump uses this material, especially the cutting-type open impeller. DN standard expresses nodular cast iron as GGG, and the American express method is Ductile iron

Two, stainless steel

stainless steel is the most widely used stainless steel is austenitic stainless steel. Except for a few media such as hydrochloric acid and dilute sulfuric acid, austenitic stainless steel is an excellent corrosion-resistant material and the most commonly used corrosion-resistant material for chemical pumps. In addition, high-alloy stainless steel (alloy 20) and double stainless steel are also ideal corrosion-resistant materials

Three, cast steel

For corrosive and harmful petroleum Products, or when the outlet pressure of the multi-stage pump reaches 13.8Mpa, the specified cast steel or cast stainless steel must be used. In boiler feed water pumps and many hydrocarbon applications, martensitic stainless steel is often used. Martensitic stainless steel has good mechanical properties and is suitable for high-pressure working conditions, but its corrosion resistance is not as good as other types of stainless steel in chemical applications and other corrosive applications. In the environment, austenitic stainless steel (CF-8M, CF-3M, etc.) is often used as a pump casing material. In addition, austenitic stainless steel can resist corrosion due to high speed and can be relatively easily welded on site. repair. High-pressure shallow sea water injection pumps have higher requirements for corrosion resistance and mechanical properties. The pump casing is made of duplex stainless steel (50% ferrite + 50% austenite)

As the strength of cast steel becomes higher, usually when the pressure is greater than 16Mpa, the pressure-bearing parts are mostly cast steel, the national standard code is ZG, the most commonly used grade is ZG230-450 Japan and the United States usually use CS to represent cast steel

Fourth, carbon structural steel

is usually divided into Katong carbon structural steel and high-quality carbon structural steel. The most representative ordinary carbon structural steel is Q235, which is mostly used in various steel plates and section steels; the most representative high-quality carbon steel is No. 45 steel, which is widely used as a pump shaft material when no corrosion is required.

Five, alloy steel

The most representative alloy steel is 40Cr, which is usually used as a material for high-strength pump shafts.

6. Non-metallic materials

Non-metallic materials for pumps are mainly used for sealing, such as polytetrafluoroethylene, fluorine rubber, nitrile rubber, etc. Among them, polytetrafluoroethylene has excellent corrosion resistance and high temperature resistance and is used for chemical pump gaskets and static seals of mechanical seals. It is suitable for almost all chemical media within 250°C. Its disadvantages are high hardness and difficulty in assembly. Big

Fluorine rubber is also a kind of better temperature resistance and corrosion resistance material. The upper limit of temperature resistance is 160℃. When the user has no special requirements, the company’s chemical pumps all use the sealing ring of this material; while the nitrile rubber is mainly used for oil resistance or Static sealing for clean water medium.

Seven, bronze

In many water pump applications, bronze materials are also used as the pump body. Lead bronze is commonly used in small low-pressure pumps, and lead helps the sealing of the pump body. Tin bronze is used as the body material for larger centrifugal pumps. Although nickel aluminum bronze has the best mechanical properties and corrosion resistance, it is expensive and not competitive

8. Composite materials

In order to improve the chemical resistance of the pump, a lining can be installed in the volute. The materials used for the lining are PTFE, rubber, etc. Monolithic ceramic and graphite pumps are used in particularly corrosive liquids, such as hydrofluoric acid in the paper and pulp industry, metal finishing industry, and composite materials (such as epoxy resin) are used to make pump bodies.

If any other questions,welcome here:www.avaengineerings.com

The post What is the material of centrifugal pump? appeared first on AVAengineering.

The post AVA Engineering 12×10 F-G Dredge and Gravel Pump with Spare Parts appeared first on AVAengineering.

MISSION Magnum I pumps are proven as reliable, heavy-duty, low-cost slurry pumps. The 3x2x13 through 8x6x14 pumps all feature the same power end, which ensures production and reduced spare-part inventory requirements. Standard models are equipped with a heavy-duty 2½-in. alloy steel shaft protected from wear by a stainless-steel shaft sleeve, double-row outboard bearings, and inboard roller bearings. They are rated for continuous service in applications up to 200 hp and are available in hard iron, stainless steel, aluminum bronze, and high Chrome with capacities up to 3,400 gal/min and pressure head up to 550 ft. Some sizes can be offered in a counterclockwise rotation giving the user more flexibility.

Mission MAGNUM I Sand Pump

AVA Engineering® as a professional centrifugal pump manufacturer in China, with more than 34 years of experience in the manufacturing and service of Mission centrifugal pumps and parts. Our pumps are specifically designed to meet the needs of some of the oil and gas drilling, mining, fluid pumping, horizontal directional drilling and well stimulation fracking.

AVA Engineering offers a complete line of centrifugal sand pumps to suit for all kinds of drilling sand pump application. Size ranges from 3x2x13, 4x3x13, 5x4x14, 6x5x11,6x5x14, 8x6x11,8x6x14, 10x8x14, 12x10x23 to 14x12x22b. Bare pumps, matching motors are available from 7.5KW to 90KW, with rotation 800, 1000, 1150,1450, 1750 to 3500 RPM at 50Hz or 60Hz.

The model 10x8x14 and 8x6x14 centrifugal magnum pump used on solid control system over 3000 meter-long drilling rigs, with big viscosity and heavy specific gravity drilling fluid. 8x6x11 centrifugal mud solid control feeding pump applies to under 3000 meter-long drilling rigs, and it also can be used to supply mud to triplex mud pump as a filling pump. 6×5×11 centrifugal pump applies to truck-mounted drilling rigs or pocket drilling rigs. 4x3x13 drilling centrifugal pump is usually used as measuring pump or replenishment pump. 3x2x13 model pump is usually used as clean water pump.

Magnum Pump Parts List:

The post China Mission Magnum 8x6x14 Centrifugal Pump and Parts appeared first on AVAengineering.
